With high-powered amplifier, FH303 delivers incredible wireless performance and coverage range. Paired with adjustable transmission power technology and three fixed antennas, FH303 enhances signal strength and extends signal range for better performance, eliminating dead spots. You'll get a strong wireless signal wherever you are in your home or apartment.
Tenda FH303 Wireless N300 High Power Router.
Wireless Routers Without Modem.
Universal Repeater provides seamless bridging to expand your wireless network.
TX button helps you adjust the wireless signal more conveniently.
Wireless security encryption easily at a push of WPS button.
WPS button 300Mbps wireless speed ideal for interruption sensitive applications.
Maximum Wireless Coverage Dead spots in your home or office can slow down your wireless access and even prevent you from getting online. Advanced High Power technology from Tenda enhances signal strength. Paired with three fixed antennas, FH303 boosts signal strength for maximum performance and range.
Universal Repeater Universal Repeater is a technology used to extend wireless coverage. Compared to the traditional WDS (Wireless Distribution System) technology, Universal Repeater not only has an easier setup method, but also provides better performance and compatibility.
Parental Control Support Client Filter、Mac Filter、Websites Filter function, you can define parental controls such as time of using, ability to block domains.
Advanced Wireless Security FH303 offers multi-level wireless encryption options to prevent unauthorized access and protect your important data. 1.64/128bit WEP、WPA-PSK、WPA2-PSK 2. Wireless Access Control based on the mac address of wireless adapter.
Client Router Mode--- WISP Client FH303 is designed to be set in Client Router Mode to support a WISP connection. When it works as a WISP client device to access the internet, local computer can connect to FH303 via wireless or cables.
WPS Button --- WI-FI Protected Setup Compatible with WI-FI Protected Setup™ (WPS), FH303 features WPS that allows users to almost instantly setup their security simply by pressing the "WPS" button automatically establishing a secure connection. Not only is this faster than normal security setups but more convenient in that you don't
TX Button --- Adjust The Wireless Signal More Conveniently With TX button, you can adjust the strength of wireless signal more conveniently. Press and hold the TX button about 3 seconds, and then release the TX button, the LED G will turn off and the LED S will turn on, then you'll get a better wireless performance.
Compliant Standard IEEE 802.3/3U IEEE 802.11n/g/b
Interface 1 10/100Mbps WAN Port 3 10/100Mbps LAN Ports
Antenna 3 fixed 5dbi Omni Directional antennas
Button 1 Reset/WPS Button1 TX(adjust the strength of wireless signal)
Frequency Range (GHz) 2.412GHz-2.472GHz
Wireless Link Rate IEEE 802.11n: up to 300MbpsIEEE 802.11g: up to 54MbpsIEEE 802.11b: up to 11Mbps
Wireless Security 64/128bit WEPWPA-PSKWPA2-PSKWPS support
Working Mode AP; Universal RepeaterWISP; WDS Bridge
Wireless Function Enable/Disable Wireless RadioWireless Access ControlAdjustable transmission power
Reception Sensitivity b mode:1M -92dBm@8% 11M -87dBm@8% PERg mode:54M -72dBm@8% PER n mode:72.2M -68dBm@8% PER 150M -68dBm@8% PER
Internet Connection Type Dynamic IP/PPPOE/Static IPL2TP/PPTP/PPPoE Dual Access
DHCP Built-in DHCP server DHCP Client List Address Reservation
Virtual Server Port Forwarding DMZ Host
Parental Control Client Filter Mac Filter Websites Filter
Dynamic DNS No-IP dyndns
VPN Pass-Through PPTP L2TP
Other Advanced Function Bandwidth Control Mac Address Clone Remote Web ManagementSystem Log
Package Contents Wireless N300 High power Router FH303 Quick Installation GuideEthernet cable Power adapter Resources CD
Environment Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certificates FCC, CE, Rohs
Product Size 19 x 12.2 x 3.2 cm
Package Size 33 x 26 x 7.5 cm
What's in the box?
1 x Tenda FH303 Wireless N300 High Power Router with TX Button
1 x Quick Installation Guide
1 x Ethernet cable
1 x Power adapter
1 x Resources CD
